UNI-T - UTi165K - Infrared Thermal Imager High-Precision Handheld Human Body Temperature Measurement Tool.
• Display 2.8" TFT LCD, Display Resolution 320×240, Visible Light Resolution 640×480, Sensor: Un-Cooled Focal Plane.
• Thermal Pixel 19200 (160×120), Pixel Dimensions 12μm, Frame Rate<9Hz, Bandwidth of Infrared Spectroscopy 8~14μm.
• Resolution: 0.1˚C, Accuracy ±0.5˚C @ 1 Mtr, Temperature Range 30˚C~45˚C, Minimum Measuring Distance 15cm.
• FOV 56°(H) × 42°(V), IFOV 6 mrad, Thermal Imaging Sensitivity<50mk, Measurement Response Time ≤500ms (95% of reading).
• 10 Navigation buttons, 3 Image Modes (Thermal Imagery, Digital Camera (visible light), Fusion), Temperature Measuring Point (1 Central point + 3 temperature measuring points can be added).
• Temperature Alarm (High / Low): Light alarm via unit only, Sound alarm via PC only "PC Analysis Software".
• Ports: Data Communication Type-C USB, Micro SD card, Tripod mounting hole.
• Power: A single Li-ion 3.7V/5000mAh 26650 battery, Service Time: ≧6 hours, Charging Time: ≦5 hours, Charging Voltage/current: 5V/2A.
• Accessories included (Manual, Type-C USB cable, 16GB TF Card), Machine Color Red.
Brand:
Uni-T
Internal Reference:
UTi165K
Specifications
Color | Red |
